Technical Specification

2 DMX outputs, 1 DMX input (can be set as output), connect to expander, open all 256 domain outputs

Built-in 1 full-view industrial 10.1-inch capacitive touch screen

6 replay faders

2 AB field manual faders

4 function encoders (with PUSH function)

1 Gigabit Ethernet port, supports MA NET, ARTNET signals, one wireless WIFI

2 USB ports, one DP output port (can be connected to an external touch display)

Independent German CHERRY yellow backlit buttons. Better feel.

MIDI input interface, LTC/SMPTE time code, audio output, built-in uninterruptible power supply

Built-in 120G solid state drive, 8G memory.

Pre-installed WIN10 64-bit customized system

Support stage 3D effect simulation, real-time on-site simulation

AC wide voltage power supply: 100-250V, 50/60Hz

Console size: 34x25x9 cm

Net weight: 3kg

Gross weight: 2.2KG
